Console Managed Package Details

The Pitcher Console Managed Package creates a foundational layer for the apps that Pitcher builds on Salesforce. It includes objects that are shared across all apps and use the PCH Namespace.

This document describes the contents and configuration of the latest Pitcher Console Managed Package.

Package Components

A Package Component is a basic building block of development. Check this Salesforce Package-able Components Documentation for different supported components which can be packaged.

Custom Objects

Pitcher Apps Managed Package installs the following five custom objects listed below:

Console

Console Object

The Console (PCH__Console__c) object determines how certain template records related to Tags, Missions, Promotions, Assortments, etc. are allocated to Accounts/Users.

Fields and Relationship

Field Label	Field Name	Data Type
Name	`Name`	Text(80)
Owner	`OwnerId`	Lookup(User,Group)
Created By	`CreatedById`	Lookup(User)
Last Modified By	`LastModifiedById`	Lookup(User)
Color (Long)	`PCH__Color_Long__c`	Long Text Area(10000)
Component	`PCH__Component__c`	Picklist
Data Type	`PCH__Data_Type__c`	Picklist
Icon	`PCH__Icon__c`	Text(255)
Label	`PCH__Label__c`	Text(255)
Label (Short)	`PCH__Label_Short__c`	Text(255)
Logic	`PCH__Logic__c`	Long Text Area(10000)
Mapping (Long)	`PCH__Mapping_Long__c`	Long Text Area(131072)
Market	`PCH__Market__c`	Text(255) (External ID)
Parent	`PCH__Parent__c`	Lookup(Console)
Sequence	`PCH__Sequence__c`	Number(18, 0)
Source	`PCH__Source__c`	Long Text Area(10000)
Visibility	`PCH__Visibility__c`	Long Text Area(10000)

Resources

Component Name	Component Type
Console Layout	Page Layout
All	List View

Lightning Web Components

These are customized, reusable building blocks of the user interface (similar to Aura components, but using newer technology).

Components

Name

Description

importExport

This is a reusable component for any type of sObject export and import.

First, a wrapper component like importExportMission has to be built
Here it’s built for Mission object

importExportMission

This is the wrapper component for the Mission object.

First, drag and drop this component to Mission Record Page
Now open any mission record which has to be exported
The exported file will be a JSON file
Now import the same JSON file in the same org to deep clone the records

Custom Tabs

Pitcher Console Managed Package installs two custom tabs.

Console - This is the only tab that appears in the Console package.

Permission Sets

Pitcher Console Managed Package installs the following two permission sets that are used for proper access to Pitcher application usage:

PITCHER-Console Rep - This permission set is used to set permissions for sales representatives and account managers for front-end usage.
PITCHER-Console Operations - This permission set is used to set permissions for business administrators for back-end (Salesforce) usage.

Apex Classes

Pitcher Apps Package installs the following Apex Classes that are used for the proper functioning of the applications on the Pitcher platform:

CTL_ImportExport
CTL_ImportExport_TST
SObjectDataLoader

SObjectDataLoader_TST
DAT_ConsoleFactory_TST

Installation

To learn how to install this package and the post-installation steps, see Installing the Console Managed Package.
